A State-of-the-Art Data center with advanced servers provides highly interactive learning environment with full fledged hardware and software training facilites. DataCenter is equipped with Ten Xeon Processor based Servers and 2 Pentium Processor Based servers and all 900+ Nodes organized in Client/Server architecture with AT & T structured cabling (both OFC and UTP) compliance. All The 900+ Nodes are distributed among all computer laboratories, adjacent to each other under one roof. The Application software available in the center is Oracle 11g, Rational Suite, Clementine , Informatica, Visual Studio.net, Turbo C++ Etc.,
All 900+ nodes in the college provide 24 x 7 accesses to intranet and internet to all the users faculty, students staff, guests, and visitors. The intranet installed at college, has advanced optic fiber cables running at 1 gbps and a star connected ring topology with high speed distributed structured CAT-6 cable network that gives a connectivity of 1 gbps to the entire campus including both girl and boys hostel. The college has high-speed multi-services enabled network infrastructure. The network is converged with integrated voice, video and data.
Datacenter was established in Dhanekula to consolidate all the app servers, DB Server and compute clusters in to a single facility to ease the maintenance and provisioning the servers and apps to users throughout the campus. All the Blocks are connected in Star Topology with this Datacenter being the central point. The Data Centre Consists of Core Switches, Router, Firewall, and HPC Servers & Common Storage System. Datacenter will serve its students to access common IT Facilities like Login Authentication, Secure Internet, Excel Knowledge Assets, Digital Repository System, Digital Syllabus Contents and more.
Datacenter monitors the campus wide networking facility of the institution ubiquities network connectivity through wi-fi. It provides high end work station, enables campus-wide access to online international journals and software's through single source, 24x7 Internet facility, hosts college website, official mailing and messaging etc.
It houses two racks fitted with servers and compute cluster nodes for hosting a variety of services like Dhanekula Attendance Monitoring system, Feedback system, Dhanekula enet, video lecture streaming etc., It hosts infrastructure amounting 1 crore approx. Dhanekula Datacenter offers internet facility throughout the campus with the help of external ISP backbones. The Datacenter has 24x7 cooling system to keep the heap emanated under control and it is endowed with 250 KVA DG with auto mode support and 20 KVA online UPS-RPS support with 2 hrs backup.
Server's
Name of the Server | Configuration |
---|---|
File Storage Server |
HPE ProLiant DL380 Gen9 Server - Intel Xeon Processor E5-2620 v4 (20M Cache, 2.10 GHz) - 2 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array p440ar/2g fio controller -1 x hpe embedded 1gb ethernet 4-port 331i adapter - 1xhp 2u sff easy install rail kit - 2 x hp 500w fs plat ht plg pwr supply kit - 1xhpe ilo firmware hpe iiLO042.0 2gb NAND - DVD R/W |
ERP Server |
HPE ProLiant DL380 Gen9 Server - Intel Xeon Processor E5-2620 v4 (20M Cache, 2.10 GHz) - 2 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array p440ar/2g fio controller -1 x hpe embedded 1gb ethernet 4-port 331i adapter - 1xhp 2u sff easy install rail kit - 2 x hp 500w fs plat ht plg pwr supply kit - 1xhpe ilo firmware hpe iiLO042.0 2gb NAND - DVD R/W |
Linux Server |
x3090Server - IBM Quad-Core X-3400 Quad-Core Intel Xeon E5410 Processor (2.33 GHz, 80 Watts, 1333 FSB)/12MB (2 x 6MB) Level 2 cache / 4 GB PC2-5300 Fully Buffered DIMMs (DDR2-667) RAM /Embedded 10/100/1000 MBPS LAN Adapter 3 x 146 GB SAS 15k RPM Hot pluggable HDD/ RPS (Redundant Power Supply) and RAID Controller Card/ 16X DVD ROM/ 19 inch LCD Monitor |
MATLAB for ECE |
HPE ProLiant DL60 Gen9 Server - Intel Xeon -Processor E5-2603 v3 (15M Cache, 1.60 GHz) - 1 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array B140i controller - 1 x hpe embedded 1gb ethernet 2-port 361i adapter - 1 x hp 1U SFF easy install rail kit - 2 x hp 900w AC 240 V DC Power module- 1x hpe ilo firmware hpe iiLO04 - DVD R/W |
Video Streaming Server | HPE ProLiant DL60 Gen9 Server - Intel Xeon -Processor E5-2603 v3 (15M Cache, 1.60 GHz) - 1 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array B140i controller - 1 x hpe embedded 1gb ethernet 2-port 361i adapter - 1 x hp 1U SFF easy install rail kit - 2 x hp 900w AC 240 V DC Power module- 1x hpe ilo firmware hpe iiLO04 - DVD R/W |
Menta Graphics Serer | HPE ProLiant DL60 Gen9 Server - Intel Xeon -Processor E5-2603 v3 (15M Cache, 1.60 GHz) - 1 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array B140i controller - 1 x hpe embedded 1gb ethernet 2-port 361i adapter - 1 x hp 1U SFF easy install rail kit - 2 x hp 900w AC 240 V DC Power module- 1x hpe ilo firmware hpe iiLO04 - DVD R/W |
Cadence Server | HPE ProLiant DL60 Gen9 Server - Intel Xeon -Processor E5-2603 v3 (15M Cache, 1.60 GHz) - 1 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array B140i controller - 1 x hpe embedded 1gb ethernet 2-port 361i adapter - 1 x hp 1U SFF easy install rail kit - 2 x hp 900w AC 240 V DC Power module- 1x hpe ilo firmware hpe iiLO04 - DVD R/W |
MATLAB for EEE |
HPE ProLiant DL60 Gen9 Server - Intel Xeon -Processor E5-2603 v3 (15M Cache, 1.60 GHz) - 1 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array B140i controller - 1 x hpe embedded 1gb ethernet 2-port 361i adapter - 1 x hp 1U SFF easy install rail kit - 2 x hp 900w AC 240 V DC Power module- 1x hpe ilo firmware hpe iiLO04 - DVD R/W |
Database Server | HPE ProLiant DL60 Gen9 Server - Intel Xeon -Processor E5-2603 v3 (15M Cache, 1.60 GHz) - 1 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array B140i controller - 1 x hpe embedded 1gb ethernet 2-port 361i adapter - 1 x hp 1U SFF easy install rail kit - 2 x hp 900w AC 240 V DC Power module- 1x hpe ilo firmware hpe iiLO04 - DVD R/W |
Xylinx Server | HPE ProLiant DL60 Gen9 Server - Intel Xeon -Processor E5-2603 v3 (15M Cache, 1.60 GHz) - 1 x 16GB 1RX4 PC4-2400T-R KIT - 3 x HP 1TB 6G SATA 7.2k 2.5in 512e - 1 x hp smart array B140i controller - 1 x hpe embedded 1gb ethernet 2-port 361i adapter - 1 x hp 1U SFF easy install rail kit - 2 x hp 900w AC 240 V DC Power module- 1x hpe ilo firmware hpe iiLO04 - DVD R/W |
Switch Details
Switch Name | Description | Qty |
---|---|---|
NAS | NAS Storage Server - ReadyNAS-4312x - Netgear Ready NAS 4312x diskless - 6 - Seagate HDD 10TB each (10TB HDD x 6 nos) | 1 |
Core Level Switches - Layer-3 Switch | Layer -3 Switch - ICX7250-24-2X10G- 24-port 1 GbE switch bundle with 2x1GbE/10GbE + 6x1GbE SFP+ (upgradeable to 10GbE) uplink/stacking ports upgrade with stacking | 2 |
Distribution Level Switches - Layer-2 Switch | SRW-2024 - SG300-SRW-2024 + 2 - Managed Switch | 35 |
UTM Firewall |
05-CRI- 0200iNG-01 - Firewall, Bandwidth Management, Multiple link Management, VPN & on appliance reporting. 05-TVSPPRC- 0200iNG-01 Total Value Subscription Plus includes Anti Malware, Anti-Spam, Web and Application Filter, Intrusion Prevention System 24x7 Support, hardware warranty and RMA fulfillment |
01 |
KVM Switch |
Raritan's EZ-116 ExpreZo EZ KVM switch 16 port with complete set of data cables and 150 ft Extension Module |
01 |
